Gravity filters take a large shop floor area. When there is restriction in space available a Compact band is suggested. As the dirty fluid is transferred using a pump, this filtration system can be placed away from the machine also.
In this filter the filter paper is held between a pair of sealing discs & a permeable support belt. Dirty fluid is dropped in the trough formed with filter paper at the bottom. The fluid passes through the filter paper leaving the dirt on it. The layer of dirt gathered on the filter paper achieves finer filtration. The filter is mounted directly on top of the tank, letting clean fluid in the tank.
Read MoreBand filter are the simplest and oldest form of filters. Veeraja ECO Band filter is one more step towards additional simplicity. This band filter does not have a moving conveyor. This eliminates the maintenance concerns of jamming and breaking of conveyor. A standard magnetic separator can also be added to improve on the efficiency of the band filter.
Read More
Vacuum filters primarily work on Vacuum principle. Vacuum is created in a chamber by pump suction or ventury.
The chamber forms the bottom portion of tank which receives the dirty fluid from machine. Filter media ( paper / mesh ) is laid on top of this chamber.
Read More
